CA-TFD-360W;CA-TFD-450W;CA-TFD-480W;CA-TFD-600W
CASOLED
94054090000
LED Flood Light
Specification:
Model No. | CA-TFD-720W | CA-TFD-900W | CA-TFD-960W | CA-TFD-1200W |
Power | 720W | 900W | 960W | 1200W |
Input Voltage | AC100-305V | |||
Material | Fin-type 1060 Aluminum | |||
Light Efficiency | 140lm/w standard, 165lm/w for optional | |||
LEDs Brand | Lumileds SMD 3030/5050 | |||
Driver | Meanwell/Sosen/Inventronics | |||
CCT | 2700K-6500K | |||
Beam Angle | 20°/40°/60°/90°/120°/140°*100° | |||
Lifespan | 50,000 Hours | |||
Warranty | 5 Years | |||
Certifications | CE, RoHs, IP67, LM-80 | |||
Product Size | 625*550*83mm | 625*680*83mm | ||
Net Weight | 18.2KG | 18.3KG | 23.35KG | 23.45KG |
1.The TFD series is another Modular design from Guohui Lighting on a more powerful scale.
2.It features a highly efficient Meanwell Driver with Philips LED chip and a powerful Lumen output 165lm/W.
3.The cost-effective and versatile lighting system suits large-sized applications, and spaces and is available for the dimmable solution.
4. ( 1~10V /DALI/Photocell/NB-LOT) and a modular Swivel version which allows adjustment of the light head for better light distribution.
5. Meanwell sery Led driver to power up the lamp, which ensure the top quality.
6. Water proof is IP67 grade.
Power: 720W/900W/960W/1200W
Material: Fin-type 1060 aluminum
Input Voltage: AC100-305V
Meawell Driver, Lumileds SMD 3030/5050
light efficiency: 140lm/w standard, 165lm/w for optional
DALI, 0-10, 1-10 Dimming
IP67 Waterproof
5 & 7 years warrany
Certifications: CE, RoHs
Application:
LED Flood Light
Specification:
Model No. | CA-TFD-720W | CA-TFD-900W | CA-TFD-960W | CA-TFD-1200W |
Power | 720W | 900W | 960W | 1200W |
Input Voltage | AC100-305V | |||
Material | Fin-type 1060 Aluminum | |||
Light Efficiency | 140lm/w standard, 165lm/w for optional | |||
LEDs Brand | Lumileds SMD 3030/5050 | |||
Driver | Meanwell/Sosen/Inventronics | |||
CCT | 2700K-6500K | |||
Beam Angle | 20°/40°/60°/90°/120°/140°*100° | |||
Lifespan | 50,000 Hours | |||
Warranty | 5 Years | |||
Certifications | CE, RoHs, IP67, LM-80 | |||
Product Size | 625*550*83mm | 625*680*83mm | ||
Net Weight | 18.2KG | 18.3KG | 23.35KG | 23.45KG |
1.The TFD series is another Modular design from Guohui Lighting on a more powerful scale.
2.It features a highly efficient Meanwell Driver with Philips LED chip and a powerful Lumen output 165lm/W.
3.The cost-effective and versatile lighting system suits large-sized applications, and spaces and is available for the dimmable solution.
4. ( 1~10V /DALI/Photocell/NB-LOT) and a modular Swivel version which allows adjustment of the light head for better light distribution.
5. Meanwell sery Led driver to power up the lamp, which ensure the top quality.
6. Water proof is IP67 grade.
Power: 720W/900W/960W/1200W
Material: Fin-type 1060 aluminum
Input Voltage: AC100-305V
Meawell Driver, Lumileds SMD 3030/5050
light efficiency: 140lm/w standard, 165lm/w for optional
DALI, 0-10, 1-10 Dimming
IP67 Waterproof
5 & 7 years warrany
Certifications: CE, RoHs
Application:
