CAMZ-S42-4W-T0
CASOLED
52*18.5 LED Modules powered by Philips
| Part No. | Color | Dimension | Input Voltage | Current | Power | Beam Angle | LED Qty | Lumens | IP Rate |
| CAMZ-S42-4W-T0 | White | 42*42*9.6 | 12VDC | ≥75 | 1.2W | 170° | 2 | 180lm | IP65 |
Features:
● Powered by high output PHILIPS LED
● Constant voltage
● Integrated transparent 170°optic lens
● 20 pcs per string
● CE, RoHS,UL,TUV, BIS, CB and LM-80 certified
Application:
● Apply to 6-15 cm depth signs at airports, metros, banks, buildings and shopping malls, etc.
Reference
Connection:
Packages
* Anti-static bag and carton
Weight/Carton | 12Kg/carton |
Quntity | 1500pcs/carton |
Package Size/ Carton | 490×450×220mm |
52*18.5 LED Modules powered by Philips
| Part No. | Color | Dimension | Input Voltage | Current | Power | Beam Angle | LED Qty | Lumens | IP Rate |
| CAMZ-S42-4W-T0 | White | 42*42*9.6 | 12VDC | ≥75 | 1.2W | 170° | 2 | 180lm | IP65 |
Features:
● Powered by high output PHILIPS LED
● Constant voltage
● Integrated transparent 170°optic lens
● 20 pcs per string
● CE, RoHS,UL,TUV, BIS, CB and LM-80 certified
Application:
● Apply to 6-15 cm depth signs at airports, metros, banks, buildings and shopping malls, etc.
Reference
Connection:
Packages
* Anti-static bag and carton
Weight/Carton | 12Kg/carton |
Quntity | 1500pcs/carton |
Package Size/ Carton | 490×450×220mm |
